Heavy duty Free-standing or Wall Mounted Single Sided Cantilever Rack for pipes and tubing products. Our pipe racks are manufactured out of strong box section steel and are fully-welded here in our factory, designed for heavy duty use and loads up to 500KG.
Perfect for storing pipes, tubing, rods, timber and other long-length items. Our Wall Mounted Cantilever Racks can be fully customised to suit your needs - just ask!
Built to maximise wall and floor space in your workplace, our Wall Mounted Cantilever Racks can be mounted to any suitable and secure wall surface and will take loads of up to (500KGs) evenly distributed across all arms.
NOTE! When you order this rack please state if you are wall or floor mounting and we will supply the rack with pre-drilled mounting points.
Overall dimensions (2x2-arm model):
1200h x 1000w x 400d
Usable length of each arm: 300mm
Distance between main support - 900mm
Each rack can be fixed to a suitable wall surface using bolts (not supplied). Purchase several racks depending on intended load weights and suitability of wall surface. Strong protective plastic end caps are fitted to each arm. Installation of our wall mounted cantilever racks should be completed by a competent person.
Simply purchase as many racks as you need depending on the length of your items to be stored.
This wall mounted cantilever rack is available in a number of different sizes and can also be further customised to suit your needs. Please enquire.
But why are our wall mounted cantilever racks so much cheaper than our online competitors?
This product is manufactured by us in our UK plant. We ARE NOT a catalogue company; therefore, we can offer you trade prices on our full range of storage racks. We can also offer discounts on volume orders.
Heavy Duty Cantilever Rack Product Specs:
Stillage Type |
Free-standing/Wall Mounted Cantilever Storage Racks |
Steel thickness |
2.5mm |
Base/Corner Steel |
40x40mm Box Section Steel |
Finish |
Supplied painted* |
Capacity |
Up to 500KGs evenly distributed across all arms. |
Unit weight |
N/A |
Safe for crane lifting? |
No. |
Product Options:
Please note: If you need a product to be customised, please visit our page for further information.
Size |
We can manufacture to any size (within reason!) |
*Please note that our blue finish IS NOT a protective coating. It’s an aesthetical finish that will eventually degrade over the course of the products lifetime. If you need a higher-grade of protection, please (please visit our page for further information).
